Construction & Civil Engineering
Generator
GVH Series
Honda GVH Series
GVH series GVH-3000 GVH-3000
| Product category |
|
| Product name |
GVH-3000 |
| AC_Rated Frequency |
50 Hz |
| AC_Rated Output |
2 kVA |
| AC_Rated Voltage |
220 V |
| AC_Rated Ampere |
9.1 A |
| AC_Rated Frequency |
50 Hz |
| DC_Rated |
8.3 A/ 12V/ 100VA |
| Engine_Model |
HONDA GX160 |
| Engine_type |
4-Stroke, overhead valve, single cylinder |
| Engine_Displacement |
163 cm3 |
| Engine_Compression Ratio |
|
| Engine_Speed |
3,000 min-1 |
| Engine_Starting Method |
Recoil |
| Engine_Cooling System |
Forced air |
| Engine_Ignition System |
Transistorized magneto |
| Engine_Oil capacity |
0.58 L |
| Engine_Starting Method |
Recoil |
| Engine_Fuel Tank Capacity |
12.6 L |
| Engine_Spark Plug |
BPR6ES (NGK) or W20EPR-U (DENSO) |
| Net weight |
42 kg |
| Gross weight |
|
| Product dimensions L x W x H |
615 mm (24.2in) x 445 mm (17.5in) x 457 mm (18in) |
| Packing dimensions L x W x H |
|
Performance curve and outline drawing
