| Product category | |
|---|---|
| Product name | SEH-80X-BBU |
| Model name | SEH-80X-BBU-5 |
| Pump_Connectiondia_Suction | 80 mm (3 '') |
| Pump_Connectiondia_Discharge | |
| Pump_Connection thread | BSP Thread (G3) |
| Pump_Total head | 26 m (85 ft) |
| Pump_Discharge volume | 930 L/min (246 USG/min) |
| Pump_Max. suction head | 8 m (26 ft) |
| Engine_Type | Forced Air-cooled 4-stroke Gasoline Engine |
| Engine_Model | HONDA GX 160 |
| Engine_Displacement | 163 cm3 |
| Engine_Rated output | 2.9 kW (3.9PS ) / 3600 min-1 |
| Engine_Max. output | 3.6 kW (4.9PS ) / 3600 min-1 |
| Engine_Fuel | Automobile Unleaded Gasoline |
| Engine_Fuel tank capacity | |
| Engine_Engine oil | |
| Engine_Engine oil capacity | 3.1 L (0.82 USG) |
| Engine_Continuous operating time | Approx. 2.0 hrs |
| Engine_Starting method | Recoil starter |
| Applicable liquids_Consistency | |
| Applicable liquids_Suspended solid percentage | |
| Applicable liquids_Max. solids size | |
| Applicable liquids_Temperature | |
| Accessories | 1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine tool set |
| Net weight | 27.0 kg (59 lb) |
| Gross weight | 30.0 kg (66 lb) |
| Product dimensions L x W x H | |
| Packing dimensions L x W x H | 525 × 389 × 458 |
1. Engine start failure.（Refer to instruction of engine）
2. Blocked impeller.（Disassemble & clean）
